Surge Arrester PV BRPV3-1000T1, T1+T2, 1000VDC, impulse current (10/350μs) Iimp 12.5kA, discharge current (8/20μs)| Imax 50kA ^In 20kA, Britec Code:
B8002
Manufacturer
:
|
Availability:
In Stock
|
Weight:
0.1234 kg/pc
|
|
|
|
|
|
Surge Arrester V-PV BRPV3-1000T, T1+T2, 1000VDC, impulse current (10/350μs) Iimp 12.5kA, discharge current (8/20μs)| Imax 50kA ^In 20kA, Britec
Features
- Status indication.
- Ucpv 600V / 1000V can be achieved.
- Category: Class I + Class II / Type 1 + Type 2.
- Protection modes: (+) → PE, (-) → PE, (+) → (-).
- Location of use: Photovoltaic systems - PV module side.
- Conform to IEC61643-31 and EN50539.
|
|
|
|
|
|
