Test-disconnect terminal WTL 6/1 STB Weidmüller, beige

The versatile and extensive range of products - from 0.05 mm² to 300 mm² - means that you have diverse options for your applications at your disposal. Hardened steel for mechanical strength and high-quality tinned copper for optimum conductivity. All materials comply with RoHS requirements and have been tested to current environment guidelines.

Technical data:
Dimensions and weights:	Width: 7.9 mm Height: 65 mm Height of the lowest version: 48.5 mm Net weight: 23.92 g
Temperatures:
Continuous operating temp., min.:	- 50 °C
Continuous operating temp., max.:	120 °C
Product information:
Descriptive text technical data:	2.5 mm² conductor with ferrule with plastic collar, with the collar optimised for diameter only (order No. 1333100000, QTY 500).
Additional technical data:
Explosion-tested version:	No
Open sides:	right
Type of mounting:	Snap-on
Version:	Screw connection, for screwable cross-connection, One end without connector
CSA ratings data:
Certificate No. (CSA):	200039-1057876
Voltage size C (CSA):	600 V
Current size C (CSA):	45 A
Wire cross section max. (CSA):	8 AWG
Wire cross section min. (CSA):	20 AWG
Rated data:
Rated cross-section:	6 mm²
Rated voltage:	630 V
Rated impulse withstand voltage:	6 kV
Rated current:	41 A
Current at maximum wires:	57 A
Pollution severity:	3
Material data:
Material:	Wemid
Colour:	Dark Beige
UL 94 flammability rating:	V-0
System specifications:
Product family :	W-Series
Type of connection:	Screw connection
Connection direction:	on side
Number of levels:	1
Number of connections:	2
No. of clamping points per level:	2
Levels cross-connected internally:	No
Mounting rail:	TS 35
End cover plate required:	Yes
Classifications:
ETIM 3.0:	EC000902
UNSPSC:	30-21-18-11
eClass 5.1:	27-14-11-26
eClass 6.2:	27-14-11-26
eClass 7.1:	27-14-11-26
