Image is illustrative
|
Sicherungs-Reihenklemme WSI 6, 6mm² 6.3A 500V, Sicherung 5x20, dunkelbeige Code:
1011000000
Price
Manufacturer
:
|
Availability:
In Stock
|
Weight:
0.0195 kg/pc
|
Volume:
0 m3/pc
|
Wholesale qty:
50pc
|
|
|
|
Fuse terminal WSI 6 Weidmüller, beige
 |
WSI 6:
The fuse terminals of the Weidmüller W Series are available in two different forms:
Fuse terminal with pivoting retaining lever
Fuse terminal with plug-in SIHA fuse holder
|
|
| |
Technical data:
|
| Dimensions and weights: |
Width: 7.9 mm
Height: 60 mm
Height of the lowest version: 62 mm
Depth: 61 mm
Weight: 19.4 g
Net weight: 18.36 g |
Temperatures:
|
|
Continuous operating temp., min.: |
- 50 °C |
|
Continuous operating temp., max.: |
120 °C |
Product information:
|
|
Descriptive text ordering data: |
Max. power loss (1.6 W) at the cartridge fuse limits the rated current. |
|
Descriptive text accessories: |
Markers only fit on one side. |
Additional technical data:
|
|
Explosion-tested version: |
No |
|
Number of similar terminals: |
1 |
|
Open sides: |
right |
|
Type of mounting: |
Snap-on |
|
Version: |
Screw connection, Fuse isolator, for screwable cross-connection, One end without connector |
CSA ratings data:
|
|
Certificate No. (CSA): |
200039-1057876 |
|
Voltage size C (CSA): |
600 V |
|
Current size C (CSA): |
10 A |
|
Wire cross section max. (CSA): |
8 AWG |
|
Wire cross section min. (CSA): |
20 AWG |
Rated data:
|
|
Rated cross-section: |
6 mm2 |
|
Rated voltage: |
500 V |
|
Rated impulse withstand voltage: |
6 kV |
|
Rated current: |
6.3 A |
|
Current at maximum wires: |
6.3 A |
|
Standards: |
IEC 60947-7-3 |
|
Pollution severity: |
3 |
Material data:
|
|
Material: |
Wemid |
|
Colour: |
Dark Beige |
|
UL 94 flammability rating: |
V-0 |
System specifications:
|
|
Product family : |
W-Series |
|
Type of connection: |
Screw connection |
|
Connection direction: |
on side |
|
Number of levels: |
1 |
|
Number of connections: |
2 |
|
No. of clamping points per level: |
2 |
|
Levels cross-connected internally: |
No |
|
Mounting rail: |
TS 35 |
|
End cover plate required: |
Yes |
Classifications:
|
|
ETIM 3.0: |
EC000899 |
|
UNSPSC: |
30-21-18-11 |
|
eClass 5.1: |
27-14-11-16 |
|
eClass 6.2: |
27-14-11-16 |
|
eClass 7.1: |
27-14-11-16 |
|
Approvals:
|
 |
|
|
File description
|
File type
|
Download link
|
|
|
|
|
|
Product data sheet
|
PDF
|
Download link
|
|
|
|
|
